Handbook of Die Design

Publisher's Note: Products purchased from third-party sellers are not guaranteed by the publisher for quality, authenticity, or access to any online entitlements included with the product.

This classic handbook provides the major formulas, calculations, cost-estimating techniques, and safety procedures needed for specific die operations and performance evaluations

BETTER PERFORMANCE IN EVERY PHASE OF DIE DESIGN AND MANUFACTURING

The classic reference on metal-stamping die design and operations just got better. Twenty-year-plus engineering veteran Ivana Suchy's Second Edition of the Handbook of Die Design now adds to its comprehensive coverage of new ways to improve processes and reduce costs, from design through manufacturing. Whatever you blank, pierce, punch, bend, form, draw, or otherwise fabricate, this reference gives you the hands-on guidance and use-it-now data you need to do it better, faster, and safer. It's loaded with at-a-glance charts, step-by-step guidelines, rules of thumb, and up-to-the-minute techniques for ensuring precision design for every type of sheet metal press working. It's the essential on-the-job tool for engineers, designers, and technicians in die design and the pressworking range of operations looking for better evaluations and greater job satisfaction.

NEW WAYS TO IMPROVE PROCESSES AND CUT COSTS

• Useful new hardware and specialized hardware
• Custom-made automated systems
• New types of pressroom equipment
• Illustrations and specifications for rotary bending techniques
• New coating processes to increase tool durability and prevent galling
• Additional strip samples and actual die design/manufacturing problems
• More detail on strain hardening of material and its effect on drawing, forming, and bending operations, and the tooling involved
• Illustrated explanations of the use of nitrogen cylinders and air springs in die manufacture
• U.S. symbols added to metric for all dimensions and math applications, including tolerance ranges

DIE DESIGN, INSIDE OUT:
Basic Die Design and Die-Work Influencing Factors * The Theory of Sheet-Metal Behavior * Metal Stamping Dies and Their Function * Metal Stamping Dies: Their Construction and Assembly * Metalworking Machinery * Blanking and Piercing Operations * Blank Calculation or Flat Layout * Bending and Forming Operations * Drawn Parts * Practical Die Design * Die Process Quality and Automation, and Die Maintenance * Springs: Their Design and Calculations * Spring Washers * Materials and Surface Finish * Die Cost Estimating

Author: Ivana Suchy
Publisher: McGraw-Hill Companies
Published: 11/01/2005
Pages: 744
Binding Type: Hardcover
Weight: 2.54lbs
Size: 9.28h x 6.46w x 2.13d
ISBN: 9780071462716

About the Author
Ivana Suchy (Mountainside, NJ) is the sole mechanical engineer at Praxis International Inc., East Hanover, New Jersey, designing storage and retrieval systems for low- and high-heat environments automatically controlled by PLC-driven components.

This title is not returnable
