Shielded-Twisted-Pair Cable Model for Chafe Fault Detection via Time-Domain Reflectometry

This report details the development, verification, and validation of an innovative physics-based model of electrical signal propagation through shielded-twisted-pair cable, which is commonly found on aircraft and offers an ideal proving ground for detection of small holes in a shield well before catastrophic damage occurs. The accuracy of this model is verified through numerical electromagnetic simulations using a commercially available software tool. The model is shown to be representative of more realistic (analytically intractable) cable configurations as well. A probabilistic framework is developed for validating the model accuracy with reflectometry data obtained from real aircraft-grade cables chafed in the laboratory.

Author: Nasa Technical Reports Server (Ntrs),Stefan R. Schuet
Publisher: Bibliogov
Published: 07/15/2013
Pages: 74
Binding Type: Paperback
Weight: 0.33lbs
Size: 9.69h x 7.44w x 0.15d
ISBN: 9781289167912

This title is not returnable
